Heavy Duty Pipe Bender-Without Bending Arm Style, CNC Pipe Bender, which controlled by PC based industrial computer,uses special softwares and technology. They are driven by multi-axis of servo motors and servo hydraulics. Advanced automatic functions, such as feeding,angle rotating, tooling change, read drawings, edit and modify programs,self-correcting rebound data, self-correcting elongation data, material loadingand unloading, inspecting tubes, failure diagnose, are available in these machines. They are mainly used in ship building, ocean engineering,petrol-chemical industry, boiler, nuclear industry and so on. Max. capability of this series of machines is OD 450 mm with min. radius 1.5D. The machineis able to bend thin/thick wall tubes and alloy tubes into complex 3D partwithout heating. High quality parts, high efficiency, high accuracy, high automatism, low cost and low labor intensity are the advantages of these machines. It is the ideal equipment of ship building, ocean engineering,petrol-chemical industry, boiler, nuclear industry and so on.

Feature Highlights

1.PC based computer adopts WINDOWS XPoperation system.

2.Auto feeding and angle rotating function.

3.Multi-radius and tooling change function.

4.Data input: Y.B.C or X.Y.Z. YBC and XYZinterchangeable.

5.Create craft files from a drawing.

6.Off-line edit software function.

7.Storage capability: non-limited.

8.Material rebound and elongationcompensation function.

9.3D Simulation and interference function.

10.Diagnoses and Warning of wronginformation.

11.Feeding Model: End grip andrecapture.

12.Program transmit: (1)Flash Disc(2)Internet (3)Compact Disc.

13.Prevention of ovality and wall thicknessreduction functions.

14.Mandrel lubrication function.
