SCM pipe bender of King-mazon is a high performance bending machine which can accurately duplicate the production pipe parts according to the needs of the Chinese market and the current industry, and is an efficient economic pipe bending device controlled by microcomputer chip technology program.Bending angle, compensation angle, auxiliary axis movement time and so on are set and controlled by man-machine dialogue. If the manual feeding machine is installed, the bending process of three-dimensional pipe fitting can be realized at one time. This type of machine is usually used in flat or simple three-dimensional pipe bending. A single clamping automatically completes the bending process of a bend radius, which is the equipment of the ordinary pipe bending process. The machine is a stable, reliable, cost-effective pipe bending equipment. A large number of applications are applied to the operation of the pipe bending process. The maximum bending diameter of the series is 450mm.

Ø A single chip  is used to control the movement of the machine. Hydraulic plane semi-automatic pipe bender, can be very quick to complete a plane bend processing.

Ø  Through artificial transposition and other auxiliary methods, it can also bend 3D tube/pipe fitting.

Ø  Optional manual carriage device, can easily bend high quality 3D  tube/pipe fitting (applicable to models below 120).

Ø  One stack tooling, and the clamping automatically completes the machining of one elbow at a time.

Ø  Bending axis, main clamp,auxiliary clamp, auxiliary push, mandrel and so on are driven by oil cylinder.

Ø  Has the automatic hydraulic auxiliary push and the automatic hydraulic mandrel function.

Ø  Mandrel has the function of returning the mandrel in advance.

Ø  PDA has the  coaction  function with the bending.

Ø  The usual bending radius should be 1.5D-5D for tube/pipe fittings, which can be increased as needed.

Ø  Can bend carbon steel, stainless steel, copper, aluminum and other materials, solid or hollow tube.

Ø  The actual bending radius is determined according to the tooling selected by the customer.

Ø  The machine needs to install tooling/die to realize bending machining of tube/pipe fitting.

Ø  Changing the tooling/die can achieve bending square, rectangular, L, C, H, shaped profiles.

Ø  Standard model are equipped with mechanical loading device and mechanical length positioning device.

Ø  The standard model uses Chinese and English operation, can choose more language operation function.

Ø  Input processing data, the system will automatically check and warn the error situation.

Ø  The bending control program is stored in the control system and called at any time.

Ø  The standard control system can store 500 groups of tube/ pipe fitting data (can be expanded).

Ø  Operate screen and PLC program control.

Ø  Bending angle through digital setting and digital control.

Ø  Separate pedal control switch for remote operation.

Ø  Password protection can be set to prevent unauthorized personnel to modify the processing procedures and operate the machine.

Ø  One tube/pipe fitting can be set to 16 different bending angles.

Ø  Real-time display of the set number of processing to be processed and the number of processing completed.

Ø  With manual, semi-automatic, fully automatic operation function.

Ø  The hydraulic oil cooling system of standard model is water cooling, the user can choose and buy air cooling.

Ø  Adjustable bending speed can be selected.

Ø  Special functions such as lengthening the piercing length or enlarging the bending radius are optional.
